This app will then calculate the area of the headland and the remaining area of the field
Fields may vary because of odd shapes but this app is a useful guide when calculating seed,fertilizer,& Sprays requirements
You can also e-mail the answer
Available in German & Polish
Field Tracer is an Android application designed to simplify GPS/GIS (Geographic Information Systems) mapping. Field Tracer delivers efficiency, improvements and cost-savings at every stage of your operation. Android support means readily available and easily affordable hardware in a variety of sizes and specifications to meet your needs.
-Works with your smart phones and tablets running Android version 4.0 or greater.
-It requires no external hardware for basic operation.
-For RTK GPS mapping the program can connect to external GPS antennas that stream NMEA data over Bluetooth.
-Dropbox is used as a platform for storing and accessing data. This means anytime access to your data from smartphones, tablets, PCs and laptops. It also means seamless back-ups and easy access for employees or customers.
Field Tracer was developed for use in:
-RTK Data collection
-Record polygons, lines and points
-Measure area and distance
-Select layers: SHP, JPEG, BMP and PNG formats (GRD coming soon)
-Organize data by clients/farms/fields
-Sync data to and from Dropbox
(Please note that this app does not offer automatic steering functionality).
This app is based on a software "Agricultural Vehicle Navigation Software for Field Operation" and a patent "JP-4572417-B2" developed by National Agricultural Research Organization (NARO).
I. App Functionality
This app displays information to assist with straight line tasks (e.g. the difference between your current position and the base line).
II. Requirements for Use
1) Compatible Devices
Compatible with Android 4.0 and above smartphones and tablets.
2) Download and Installation
Please download and install from Google Play.
This app is available as a free, ad-supported download. Use is also free of charge.
(Please note that if you click on an ad in the guidance screen you will be directed away from the screen).
In the future an ad-free app (￥500/month ￥4,800/year) and a version with field and task management functionality (price TBA) are planned for release.
III. Demo Display Mode
This app has a demo display mode (Playback Recorded Task). In this mode, recorded location data is played back, with all other functionality (map zoom in/out, path/task width setting) the same as you would experience in normal use.
IV. Required Peripherals When Using App in Agrigultural Tasks
The app can operate using the inbuilt GPS of your smartphone or tablet but location accuracy my be low and as such use may be impaired (particularly during in-cabin use, etc). It is strongly recommended that you use a USB connected GPS/GNSS.
This app supports NMEA 0183 messages (GxGGA, GxVTG, GxRMC, HEROT, HEHDT).
For known GPS/GNSS compatibility please refer to a list below. The range of compatible devices will be increased in further version updates.
- Dual XGPS160.
Supports SPP(Serial Port Profile) connection.
u-blox's GPS/GNSS (5 to 8 series) with USB interface
- GPS receiver GPS Module with Antenna USB interface G Mouse VK-162
You can see some GPSs in eBay or Aliexpress with search word "u-blox usb" or "ublox usb".
- Change params of GPS/GNSS via 'u-center' of u-blox is needed.
FTDI's chip based USB to RS232 converter and GPS/GNSS with RS232 interface
- You can connect several GPS/GNSS (just like Hemisphere A325 Smart Antenna).
- Baudrate is limited to 9600bps currently.
TCP port connection with RTKGPS+
- TCP port number can be changed.
Not Compatible GPS/GNSS
Prolific's and Silicon Labs' chip based USB to RS232 converter and GPS/GNSS
- BU-353S4 SiRFstarIV
- HOLUX M-215+
- MediaTek's based
2) Mountable Devices
It is possible to mount your device to tractors and other vehicles using a RAM mount or similar product.
3) Cables (USB Cable, Power)
Connector cable for consumer smartphones and tablets (USB-OTG cable).
USB extension cable for GPS.
In-vehicle USB power.
V. Known Issues
1) Operation becomes unstable after long periods of use due to the lengthening of task histories.
When problems (e.g. slow response) begin occurring delete the task history from the GPS guidance settings menu or try restarting the app (please note that while guidance settings are retained when restarting task history will be deleted).
Ekylibre est une application web de gestion agricole libre. Il permet de centraliser la plupart des données de gestion de l'exploitation au même endroit pour limiter toutes les ressaisies. Il permet d'effectuer sa traçabilité totale, sa gestion commerciale, de stocks, de tiers et la comptabilité générale.
Harrison Ag has recently ported the software to the Android operating system and has published this beta version Demo application for evaluation and comment by our users and distributors. It is almost a full featured version of the production software but has limited configuration ability and the USB communications are disabled. To make evaluations possible without the need to actually operate a sprayer, a vehicle simulator is incorporated into the Demo software. Once the navigation map is displayed (by pressing "Show Map" from the start up screen) the speed of the vehicle simulator can be adjusted by simply swiping the right edge of the touch display. Similarly the simulator heading is steered by swiping the top edge of the display.
This software, and the production software, was NOT developed for use on generic Android hardware devices. Currently the only devices that it is proven to operate with are the Motorola Xoom , Xoom2, and XYBOARD. The application requires an OpenGL GPU and a large display format. As requests are made for other devices Harrison Ag will test the device/software to verify functionality.
This beta version is also missing the online user documentation. Hopefully the menus and UI are intuitive enough for an operator familiar with the Smart Nozzle system to effectively navigate to the appropriate preferences and controls. The only controls that do not use menus are the guidance control markers and the automatic steering. The "A" and "B" points can be set by a long touch on the navigation map. A dialog will be displayed that will allow the control points to be set. In the same dialog the user has the option to toggle the display mode for vehicle following or manual panning. Once both the "A" and "B" points are set, Smart Nozzle will display the master control line in red and the local control line in yellow. A "Light Bar" icon will be displayed at the bottom of the touch screen to help with manual steering. After the control points are established the user can activate automatic steering by simply double tap the navigation map.
● Electronic map fields: measuring the area and perimeter of fields. With the help of GPS or manualy (field editor).
● Maintenance history crop on each field. The history of crop rotation.
● Keeping of Farm Journal (fertilizing, planting, harvesting).
● Points of interest: the establishment of a framework arrangement of objects in your household (warehouses, gas stations ...).
● Note anywhere in your field. (Soil sampling for agrochemical laboratory)
● Storing data in the cloud. Reliable storage of your data. Transferring data to a new device.
● Web acces to your data.
● Inventory (Materials calculation in Farm Journal)
● Photo in Farm Journal
● Export fields in format SHP, KML. Sending data via email
● Export POI to KML
Multi Users package
● GPS Tracking vehicles
● For agronomist .Planning the maintenance of cultivation and operational activity in the fields via a remote mobile device
● For director/owner farm manager. Maintenance of direct cost strategic planning and compiling of analyticalactivity reports at any time
● For engineer. Tracking the work of transportation in real time analysis of
reports concerning the amount of completed work vehicle
mileage & fuel consumption
● For accountant. Analysis of reporting summaries of working hours, quantity
of work, and gross payroll numbers
Our site: http://efarmer.mobi
