Noir Pro: USB Camera HDMI Link

GuoPing He

About this app

PRO FEATURES

1. No Ads, Zero Tracking
2. 3D LUTs
3. Waveform Monitor
4. Histogram
5. Edge Detection
6. False Color
7. Zebra
8. Color Separation
9. CRT Filters
10. FSR 1.0
11. Pinch to Zoom
12. Stretch and Crop
13. Anamorphic Lens Support
14. Brightness, Contrast, and Saturation Adjustments
15. App-specific Volume Control
16. Picture in Picture Mode
17. In-app Screenshot

To use your device as a portable display for a gaming console, laptop, camera, or any other HDMI-output device, you need a USB-C capture card (not USB-C hub nor USB-C to HDMI cable).

Camera, Endoscope and Microscope with USB streaming feature are also supported.

Noir supports UVC video streaming and UAC audio streaming, offering a choice between OpenGL ES and Vulkan for the graphics backend.

COMMON USE CASES

1. Camera Monitor
2. Primary Monitor for Gaming Console & PC
3. Secondary Monitor for Laptop
4. Drone Monitor
5. Compatible with any device with HDMI Output or USB Streaming

RECOMMEND VIDEO CAPTURE CARD

Hagibis UHC07(P) #AD
Rec. Reasons: Affordable, I recommend the UHC07P if available. It supports convenient PD charging.
https://bit.ly/noir-hagibis-uhc07

Genki ShadowCast 2 #AD
Rec. Reasons: Portable, Elegant, and Beautiful.
Known issue: Needs USB adapter to work with Pixel devices (Tensor SoC).
https://bit.ly/noir-genki-shadowcast-2

FAQ

1. Why doesn't Noir recognize my device?

Possible reasons are that your phone or tablet does not support USB Host (OTG) or the device you are using isn't a Video Capture Card.
In some rare cases, you may need a USB adapter or USB hub to ensure the capture card works properly.

2. Why is the preview so laggy?

This is often due to the USB version.
If you are using a USB 3.0 capture card, ensure that both the USB data cable and the USB port on your phone or tablet are USB 3.0 compatible.
If you are using a USB 2.0 capture card, ensure the video format is MJPEG and does not exceed 1080p30fps. Note that some capture cards may support up to 1080p50fps.

3. Why did my capture card, which was working fine, suddenly fail to connect?

This issue is often caused by system problems. The simplest and most effective solution is to restart your phone or tablet and try again.

4. Why does my gaming console or Video playback device show a black screen when connected?

This issue is more common among PS5 and PS4 users and is caused by the gaming console enabling HDCP. To resolve it, go to the PS console interface: Settings > System > HDMI, and disable the 'Enable HDCP' option. Note that the PS3 does not allow you to turn off HDCP. Other devices may also automatically enable HDCP when playing video content, which can result in a black screen. Some HDMI splitters can bypass HDCP restrictions and may serve as a workaround.

LINKS

Special thanks to Genki for helping Noir grow
https://www.genkithings.com/

Special thanks to Hagibis for recommending Noir
https://www.shophagibis.com/

Font
https://www.fontspace.com/munro-font-f14903
https://fonts.google.com/specimen/Doto

Bottom Bar Design
https://dribbble.com/shots/11372003-Bottom-Bar-Animation

Ratings and reviews

Great app! I use it with my cellphone connected to my Nikon Z6II via a USB-C capture card and it works great! The developer is FANTASTIC and responsive. I asked them if there was an option to stretch the output image for anamorphic lenses and they said there wasn't, but they would look into it. A short while later, they emailed me to let me know the feature was added! The feature is exactly what I needed. Awesome overall!

Professional videographer. Amazing Monitor app, best I tried so far. Also able to add Rec 709 LUT options of my Sony cameras in Slog mode. PLEASE add HUE color control. Thanks

works ok on my pixel 6,but my s22 ultra not workinkig,message with screen freez try restart,tryed everything,dosent want to work on it,stil i like how simple the ap is thats why i purchased,and lucky i can use the pixel 6 as video monitor on a canon 90d with ugreen videocapture card

What’s new

I’m excited to share that we’ve collaborated with a designer to create a brand new set of icons. This wouldn’t have been possible without your support. I hope you enjoy them!

1. Android 16 Support
2. Experimental Hardware-Accelerated Rendering
3. Buffering Mode
4. Unify CRT Scanline, Add CRT Lottes
5. Waveform monitor
6. Color Separation
7. Custom toolbar
8. Saturation adjustment
9. Rule of Thirds
10. Other bug fixes and performance enhancements
